Excellent Services started Construction in 1985. It is one of the leading construction company in Karachi, Pakistan.
Our globalize approach through our vast international experience in construction and housing gives us the edge in providing the best to anyone who cherishes comfort and class in their home and living environment.

COMPRESSED NATURAL GAS TRANSPORTATION

Excellent Services Bulk CNG Transport Presentation

CNG FACTS AND INFORMATION
CNG is natural gas (NG) compressed for the purpose of simplified transport and storage.
Bulk CNG transport technology is not new, it is well-proven – CNG has been successfully transported on land by road-trailer (trucking) for over thirty years. The upscaled application of proven CNG technology to a marine (shipping) transport system is new.
For storage and transporting, natural gas is compressed into special tanks, gas containment tanks (GCTs) normally to a pressure of 200 to 250 bar or 2900 to 3600 psi. The NG capacity of a GCT, termed in standard cubic feet (scf) or metres (scm), depends on the volume of the GCT, working pressure, temperature and composition of the NG. GCTs are mainly cylindrical and vary in diameter and length and can be made of steel or lighter-weight composite materials – one technology uses coiled small diameter pipe for marine transportation.
Feedstock gas for compression can be sourced from a natural gas field (onshore or offshore), an existing natural gas transmission pipeline (PLG), a coal mine as coal-seam-gas (CSG) or coal-seam-methane (CSM), biogas and also can be from flared gas.
Pressurized Natural Gas (PNG) is another term for CNG.
CNG LAND – ROAD AND RAIL TRANSPORTATION
Land CNG transportation includes both road and rail projects.
A bulk CNG road delivery system is considered best suited for short range projects, normally under 200km one-way, with continuous end unloading supply and low storage requirements. A CNG project system is normally designed around the main criteria of annual and daily volume of NG required and route distance.
A total CNG supply chain system comprises: loading compression station, trucking for haulage of the CNG trailers (CNGTs), and the market unloading decompression (pressure letdown and flow control) station. All projects are different in system requirements, for a specific project the system is modelled and designed from case study.
CNG can be transported in ISO CNG-Skids (CNGSs) by either road or rail either in a separate or combined (intermodal) project. CNGSs have a cartridge cluster of cylinder gas containment tanks or GCTs (tubes) that can be of varying size and volume and NG capacity. A standard type of CNGS is 40’ (12.2m) with a NG capacity of between 4,000 scm and 10,000 scm.
For road transport, the CNG-Skids are ISO containers that can be fitted onto an ISO trailer-chassis, combining to make an ISO CNG-Trailer (CNGT). A CNGT can have a NG capacity of up to 350,000 scf or 10,000 scm (365 GJ energy) at ambient temperature. A CNGT is sometimes referred to as a tube-trailer. The CNGT can double as both transport and storage. A road train of a three CNGT combination can carry a gross payload around 1,050,000 scf (30,000 scm) or 1,100 GJ of energy.

As previously mentioned, the CNG-Skid can also be installed inside an ISO shipping container (CNG Container) which can be chilled down to –40F using a special (non-mechanical) liquid CO2 (LCO2) fuelled refrigeration (proprietary) system. This unique Chilled CNG Container (developed by CNGI) has the ability to increase a CNG Container payload by up to 30% from ambient temperature. Using light-weight CNG cylinder technology inside the 45ft Chilled CNG Container, a gross payload of 460,000 scf (13,000 scm) is achievable = maximising payload. The Chilled CNG Container at a total gross weight of 65,000 lbs or 29,500 kg is specially designed for intermodal transportation, particularly suited for road application. A road-train of three Chilled CNG Containers (if regulations allow like in Australia on certain road routes) has a combined gross payload capacity capability of up to 1,380,000 scf (39,000 scm) or 1,450 GJ.
For rail transport, the ambient CNG-Skids or Chilled CNG Containers are loaded direct onto the flatbed railcar and can be double-stacked thus, in this case, one flatbed can carry up to 700,000 scf / 20,000 scm (ambient) or 920,000 scf / 26,000 scm (chilled). CNG-Skids can also be used as fuel tanks for providing NG for dual-fuel (gas-diesel) converted locomotives.

Excellent Services Bulk CNG Transport Presentation

KEY COMPETENCIES / AREAS OF EXPERTISE
•    Executive Management
•    Business Formation and Operating
•    Business and Trade Commercial Viability Assessment
•    Due Diligence
•    Business Shipping and Transportation Solutions
•    Business Modelling and Planning
•    Risk Analysis and Mitigation Planning
•    Project Management
•    Transport Management | Operations Management | Commercial Management
•    Crew Management
•    Marketing and Sales
•    Public Relations

MANAGEMENT
We provides management services for natural gas, CNG or LPG, supply and transportation projects –

Management Services include:

• Project Management
• Acquisition and Procurement Management
• Risk Management
• Operations Management

PROJECT WORK SCOPE
Typical Work Scope of a CNG or LPG Project
Project Process:
Phase-1 Consultation
Phase-2  Appraisal
Phase-3 Evaluation
Phase-4 Planning
Phase-5 Development
Phase-6 Commissioning
We can undertake, lead, or participate in any or all of these project phases.

ENGAGEMENT
Engagement of our team is on a fee-for-service basis. Flexibility of hourly, capped daily rates or negotiated lump sum payment options.

Setup LPG Auto Gas Station to existing site of CNG Stations.

Different CNG Stations are approaching this office to set up LPG auto Gas station at adjoiningto existing site of CNG Stations. As you aware no individual can set up LPG Auto Gas Station.
It can only be set up on the recommendation of Gas Company which have already obtained Gas storage license. We have an agreement within two companies which have already finalized different LPG auto Gas Station at different sites. We have still room to set up LPG Station.

We are providing the Following services to set up LPG auto Gas station at existing CNG Stations or at new sites.

1. To prepare documents and take all the steps involved in the setting up LPG auto Gas Station

2. To obtain OGRA provisional license and all NOCs from different departments whichever applicable

3. Finalization of Gas supply agreement with client and Gas company

The overwhelming success of our services is only because we offer the best services at the minimum cost. You are comforted of all the worries and mental burden. We shall plan the entire project and will help to tale all activities. Either visits this office or call on given numbers. Detail of Govt fees and other service charges are given at annexure I. All agreements will be signed with the client at head Office duly approved by chairman (ALC). All payments will be made through cheque in the firm account only.
